| カテゴリ: | 燃料供給パイプ | 部品番号: | 600-311-3600 600-311-3601 600-319-3601 |
|---|---|---|---|
| 製品名: | 燃料フィルター ウォーターセパレーターAssy | 機械番号: | PC210 PC220 PC230NHD PC240 PC290 |
| アプリケーション: | 掘削機,車輪積載機,ブルドーザー | リードタイム: | 配達のために1〜3日 |
| パッキング: | 標準輸出カートン | ||
| ハイライト: | Komatsu excavator fuel filter,PC220LC-8 water separator,excavator spare parts filter |
||
600-311-3600 600-311-3601 Fuel Filter Water Separator Assy KOMATSU Excavator Spare Parts For PC220LC-8
Specifiion
| Category | Fuel Supply Piping |
| Name | Fuel Filter Water Separator Assy |
| Parts No | 600-311-3600 600-319-3600 600-311-3602 600-319-3602 |
| Machine Number | PC210 PC220 PC230NHD PC240 PC290 |
| Lead time | 1-3 DAYS |
| Quality | Brand new, OEM quality |
| MOQ | 1 PCS |
| Means of transport | By sea/air, DHL FEDEX UPS TNT |
| Packing | As request or standard packing |
| Working Principle | 1. Contaminated diesel fuel from the tank enters the assembly through the inlet port and flows into the filter housing |
| 2. Fuel passes through the synthetic fiber element: 10 渭m particulate contaminants (dirt, rust, metal shavings) are trapped; hydrophobic coating repels free water, which settles into the bottom collection bowl | |
| 3. Clean, water-free fuel exits through the outlet port to the fuel injection pump and injectors | |
| 4. Accumulated water in the bowl is drained manually via the drain valve (or automatically if equipped with an electric drain) | |
| 5. The anti-drainback valve keeps fuel in the filter during element replacement, ensuring immediate fuel flow on engine startup | |
| Core Functions | 1. Particulate Filtration: Removes 10 μm+ contaminants from fuel to prevent abrasion of precision fuel injectors and pump components (a leading cause of engine power loss and injector failure) |
| 2. Water Separation: Eliminates free water from diesel fuel to avoid corrosion of fuel system metals and injector nozzle clogging | |
| 3. Fuel System Protection: Maintains clean, dry fuel supply to the engine, extending service life of injectors, pumps, and fuel lines | |
| 4. Operational Safety: Visual/electronic water alerts prevent engine damage from water-contaminated fuel; easy drain valve reduces maintenance downtime |
BULLDOZERS D65EX D65PX D65WX
ENGINES SAA6D107E
EXCAVATORS PC210 PC220 PC230NHD PC240 PC290
GRADERS GD655 GD675
WHEEL LOADERS WA250PZ WA320PZ Komatsu
| 20Y-979-6261 FILTER |
| D155A, D155AX, D65EX, D65PX, D65WX, D85PX, DRAWBAR,, HM250 |
| 702-21-53120 FILTER |
| BUCKET, CARRIER, PC130, PC220, PC240, PC290, PC300, PC350, PC400, PC450, PC45MR, PC88MR, PRESSURE, RAIN |
| 14X-911-7750 FILTER |
| D155A, D155AX, D275A, D375A, D475A, D475ASD, D85EX, D85PX, DRAWBAR, |
| 708-2L-25480 FILTER |
| CARRIER, D31EX, D31PX, D37EX, D37PX, D39EX, D39PX, PC130, PC220, PC300, PC350, PC400, PC450, PC45MR, PC55MR, PC88MR, PRESSURE, RAIN |
| 426-07-32441 FILTER |
| AIR, BATTERY, FRONT, HM250, HM300, HM400, HYDRAULIC, WA150, WA150PZ, WA200, WA320, WA320PZ, WA380, WA430, WA500 |
| 418-18-34110 FILTER ASS'Y |
| BATTERY, FRONT, WA100, WA150, WA150L, WA150PZ, WA200, WA200L, WA200PT, WA200PTL, WA200PZ, WA250, WA250L, WA250PT, WA250PTL, WA250PZ, WA270, WA320, WA320L, WA320PZ |
| 208-979-7620 FILTER |
| PC130, PC220, PC240, PC290, PC300, PC350, PC400, PRESSURE, RAIN |
| 708-2L-25480 FILTER |
| CARRIER, D31EX, D31PX, D37EX, D37PX, D39EX, D39PX, PC130, PC220, PC300, PC350, PC400, PC450, PC45MR, PC55MR, PC88MR, PRESSURE, RAIN |
| 708-2L-25480 FILTER |
| CARRIER, D31EX, D31PX, D37EX, D37PX, D39EX, D39PX, PC130, PC220, PC300, PC350, PC400, PC450, PC45MR, PC55MR, PC88MR, PRESSURE, RAIN |
| 23A-60-13601 FILTER ASS'Y |
| GD505A, GD510R, GD511A, GD521A, GD525A, GD605A, GD611A, GD621A, GD621R, GD623A, GD625A, GD661A, GD663A |
| 427-S05-3920 FILTER |
| WA600, WA900, WD900 |
| 20Y-04-K2320 FILTER |
| PC130, PC160, PC180, PC200, PC210, PC220, PC230NHD, PC290, PC340, PC450, PW170ES, PW220 |
| 9474-9404A FILTER;OPTION |
| SOLAR |
| 207-62-71100 FILTER ASS'Y |
| PC300, PC300HD, PC300LL, PC340, PC350, PC360, PC380 |
| 21T-38-31350 FILTER ASS'Y |
| PC2000, TRAVEL |
| 3EA-15-11610 FILTER |
| FD10/15, FD10C, FD10LT, FD15, FD18, FD20, FD20/25, FD20H, FD20H/25H, FD20J/25J |
| Pos. | Part No | Qty | Parts name | Comments |
| 6754-71-7400 | [1] | Filter Assembly Komatsu | 2.475 kg. | |
| ["SN: 70001-UP"] analogs:["6754717401", "6754717402"] |1. | ||||
| 1. | 6754-71-7200 | [1] | Head Komatsu | 1.05 kg. |
| ["SN: 70001-UP"] | ||||
| 600-311-3600 | [1] | Cartridge Assembly Komatsu | 0.97 kg. | |
| ["SN: 70001-UP"] analogs:["6003113601", "6003193601", "6003193600", "6003113602", "6003193602"] |1. | ||||
| 2 | 600-311-3610 | [1] | Cartridge Komatsu China | 1 kg. |
| ["SN: 70001-UP"] analogs:["6003113620", "6003193610", "6003193610", "6003113620", "6003193610"] | ||||
| 3 | 600-311-3640 | [1] | Bowl Komatsu | 0.185 kg. |
| ["SN: 70001-UP"] | ||||
| 4 | 600-311-3660 | [1] | Valve Komatsu | 0.02 kg. |
| ["SN: 70001-UP"] analogs:["6003113710", "6003113711"] | ||||
| 5 | 600-311-3720 | [1] | Sensor Komatsu | 0.05 kg. |
| ["SN: 70001-UP"] analogs:["6003113721", "6003113680", "6003113722"] |
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
